PLD7400-50/65DR-U U-Arm Digital Radiography System DR X Ray Machine

Digital X-ray – the direct digital radiography system .The complete solution for digital x-ray applications in medicine. DR supplies highest quality x-ray images with a lower dose rate simultaneously. And you can get it for a very favorable price – compare to other DR-systems on the market!
Furthermore our DR device reduces your current labor costs extensively. It eliminates the need for cost-intensive film processing:
• No extensive archive
• No waste disposal
• No chemicals
• No films

  • Product Description
  • Technical Parameters
  • Video

U-Arm Digital Radiography System DR X Ray Machine Description:

With the digital radiography system you do all current radiography duties with one device. You are going to work with one of the most modern, economic and efficient x-ray technologys. Your patients will be treated with a considerably lower radiation dose. X Ray DR machine is a general-purpose digital radiography system that offers maximum flexibility with intuitive controls for optimal workflow and clinical productivity.

U-Arm Digital Radiography System DR X Ray Machine Features:

1. DR – direct digital radiography for orthopedics, surgery and thorax diagnostic.

2. Electric control multi-angle, mA, kV, to meet the whole body position imaging.

3. Compared with film technology, digital X-ray images complete diagnosis in less time by eliminating all working steps of development.

4. By the use of the scanning-method your patients are exposed to a much lower radiation dose compared to conventional X-ray systems.

5. Fast exposure provides the best images, which can be scaled and edited.

6. By the tiltable exposure system it saves space and it`s suited very well for exposures of the standing, seated or recumbent patient.

7. For the treatment of the lying patient, different examination tables are available .

8. Integrated PC system, which can exchange data and image information quickly and improve the efficiency of surgical workflow.

9. Both U-arms offer a wide range of vertical and SID strokes, perfect for head-to-toe comprehensive imaging.

10. High power, more penetrating force, can deal with obese patients.

digital radiography system,x ray machine,dr machine

Imaging pictures:

digital radiography system,x ray machine,dr machine

digital radiography system,x ray machine,dr machine

Model PLD7400-50DR-U PLD7400-65DR-U
X-ray Generator(include console) Output Power 50KW 65KW
Power Voltage 380V±38V
kV range 40~150kV
mA range 10~630mA 10~800mA
mAs range 0.1 ~630mAs
Exposure time 0.002~6.3S /
Loading time / 2~10000mS
X-ray Tube Small focus 0.6
Large focus 1.2
Anode speed / 9700r/min
Radiographic Table Top Table Size 2020mmX690mmX680mm
Load-bearing Less than 200kg
Movement Wheels
DR Machine Frame Up&Down Moving Range 700mm ~ 1700mm
Rotating Range 0°~ 105°
SID 1000mm ~ 1800mm
