Radiolucent Surgical Table Fracture Table Surgery Description：

The radiolucent surgical table provides accurate positioning while ensuring patient comfort. These tables are made of high quality stainless steel and can withstand extreme loads in a variety of configurations. The vertical mobility of the maximizes patient imaging efficiency. The table is made specially to meet demand of general surgical operations. Designed for increasingly complex surgical cases, patients are located in a comfortable, safe and efficient manner with minimal effort and time.

Radiolucent Surgical Table Features：

General features:

1. Four parts of the desktop, including the head, back, hips and legs, all parts are suitable for X-ray use, and each part has an X-ray black box layer.

2. T-shaped base design provides the surgeon with the most ergonomic and convenient operation.

3. Waist bridge for urological surgery and other special occasions.

4. Base, column and side cover are made of high quality 304 stainless steel, corrosion resistant and easy to clean.

Technical Features:

1. Electro-hydraulic control must be adopted for lifting, Trendelenburg/ reverse Trendelenburg, left-right tilt and translation

2. Specially designed hydraulic system and improved electrical system. (Optional full set of international brand hydraulic system (Germany Hoerbiger) or Taiwan system to make the table low noise, safe and reliable)

3. Electrically slide 350mm horizontally to create a larger view of the C-arm.

4. Using micro touch remote control, any action can be very convenient to adjust, optional column auxiliary control panel.

5. Four 125mm casters, hand controllers equipped with safety locks to avoid accidental table movement.

6.One-button reset function, only one button can restore the operating table to the horizontal zero position;

7. One – bond buckling anti – buckling. Easy to meet the needs of surgery.

8. The head plate and leg plate are controlled by imported air spring, and the leg plate is separable and removable

Electrical characteristics:

1. Optional spare battery system can continue to power the table for several hours in case of power failure.
