HBJH20-1A/B/C Hospital Neonate Newborn Baby Transcutaneous Bilirubin Measurement Jaundice Detector

  • Product Description
  • Technical Parameters
  • Video

Infant Jaundice Detector, Neonatal Jaundice Detector, Newborn Bilirubin Measurement, Hospital Baby Jaundice Detector, Medcal Infant Jaundice Detector





Model HBJH20-1A HBJA20-1B HBJA20-1C
Checking methods Compare the blue and green light Compare the blue and green light Compare the blue and green light
Indication Two-figure LED digital display Three-figure LED digital display (one decimal digits) Three-figure LCD digital display (one decimal digits)
Readable Switch the measured value into the bilirubin value according to the comparative table



Test the bilirubin value directly on the forehead of baby Test the bilirubin value directly on the forehead of baby
Average counting No No Can calculate the measured average values for 2-5 times automatically
Test deviation 00~20±1

21~40±2

0~15±1

16~25±1.5

0~15±1

16~25±1.5

Light resource Xenon-flashing light Xenon-flashing light Xenon-flashing light
Power supply Nickel xenon battery No.5 of 4pieces Nickel xenon battery group 4.8V Nickel xenon battery group 4.8V
Prepare time of start-up <10s <10s <5s
Charger Input 220V 50Hz Output 6V 0.3ADC Input 220V 50Hz Output 6V 0.3ADC Input 220V 50Hz Output 6V 0.3ADC
Checkout White screen indicates 00 or 01 Yellow screen indicates 20.0±1 White screen indicates 00 or 01 Yellow screen indicates 20.0±1 White screen indicates 00 or 01 Yellow screen indicates 20.0±1
Product Weight About 340g About 245g About 190g
Product siz 171mm*74mm*41mm 163mm*66mm*37mm 161mm*53mm*30mm
Gross weight

30kg

Packing dimension

30cm*25cm*15cm
