AOT-DT-350D Electrical Single Arm Anesthesia Pendant Surgical Tower

For the operating room area is small (< 35 square meters), and the anesthesia machine position is relatively fixed operating room, according to the site conditions can be selectively configured with hanging column or rotary arm anesthesia tower, and equipped with active anesthesia exhaust emission system, taking into account the convenience of operation and safety.

  • Product Description
  • Technical Parameters
  • Video

Electrical Single Arm Anesthesia Pendant Description:

The anesthesia pendant is used to set up an anesthesia working area. It integrates anesthesia machine, monitor, infusion pump, and anesthesia information station to facilitate rapid movement and maximize the convenience of anesthesia operation.

The electrical pendant covers the entire anesthesia area, and can easily locate the equipment in the ideal position, providing air source, power supply, data communication interface, cables and pipelines for the related equipment in the anesthesia area, so that the equipment and cable management in order, so as to improve the work flow and improve the working environment.

anesthesia pendant,electrical pendant,single arm pendant,surgical tower,anesthesia machine

Electrical Anesthesia Pendant Surgical Tower Features:

1. It is convenient to use in anesthesia environment and fully meet the needs of purifying environment.

2. With lifting function, it is more convenient to move and locate.

3. Pneumatic brake can better ensure the stability of the medical crane tower and prevent drift.

4. Unique hook design, can realize the anesthesia machine and move at the same time.

5. 340° smooth rotation, comprehensive coverage of nursing area, ICU is an essential bearing platform.

6. Single-arm and dual-arm configurations are available.

7. Drawers and file partitions can hold medical devices.

8. Applicable to operating room, endoscope room, anesthesia room, hospital ward, etc

9. While meeting the requirements of general gas and electricity, air source ports such as laughing gas and exhaust gas emissions are added for the special requirements of anesthesia surgery, giving full consideration to the needs of doctors and patients.

anesthesia pendant,electrical pendant,single arm pendant,surgical tower,anesthesia machine



AOT-DT-350D
Working power AC220V 50Hz
Moving radius 1000mm
Lifting range 300mm
Material High-strength aluminum alloy
Surface treatment Electrophoresis and powder coating
Level Rotation Angle 340°
Standard Gas Outlets O2*2, VAC*2, AIR*1, N2*1, CO2* 1,N2O*1, AGSS*1
Tray 1 pcs
Sockets 8 pcs (220V/10A)
Grounding Terminal 2pcs
Network interface  RJ45 1 pc
Drawer 1 pcs
Stainless steel  infusion pump rack 1 sets
Net load 350KG
Single tray net load 80kg
