F4 8.0 Inch Veterinary Monitor Pet ECG Monitor Patient Monitoring Systems

Multi-parameter veterinary patient monitor is an intuitive, multi-functional and accurate monitoring of the veterinary market. Compact design and high resolution displays make them easy to use and understand. ECG, SPO2, NIBP, RESP, TEMP configuration are standard configurations for these monitors.

  • Product Description
  • Technical Parameters
  • Video

8.0 Inch Veterinary Monitor Pet ECG Monitor Patient Monitoring Systems Description:

Veterinary Monitor is convenient to use and carry, and is suitable for animal clinics and families. Pet monitor has six parameters: ECG, SPO2, NIBP, respiration, temperature, and pulse rate. Patient Monitoring Systems has a wealth of monitoring capabilities for cats, dogs and other animals. The ECG Monitor integrates parameter measurement modules, displays, and recorders into a compact, portable device. A replaceable battery built into its Vet Monitor also facilitates mobility.

veterinary monitor,pet monitor,patient monitoring systems,ecg monitor,vet monitor

8.0 Inch Veterinary Monitor Pet ECG Monitor Patient Monitoring Systems Features:

Body

1. 8.0 inch high-brightness TFT LED
2. Support display maximum 8 waveforms
3. Support 6 channel ECG waveform display simultaneously

Stroage

1. Support storage of 168 hours trend table and graph review
2. 100 minutes waveform review
3. 500 groups NIBP review
4. 100 hours of parameter alarm events review and associated parameters

Alarm

1. Three-level acousto-optic alarm
2. Sensor-off alarm
3. Paper out alarm
4. Support alarm review
5. Support alarm pause

Operating System

1. Multi-display mode to meet different clinical requirement, including standard interface, big font, OxyCRG, trend graph, NIBP review and full leads ECG interface.
2. NIBP self-test mode: including overpressure test, static pressure test and air leakage test.
3. 15 types of Arrhythmia analysis and real-time S-T segment analysis and pacemaker detection
4. Drug calculation and titration table
5. Support multi-language display
6. Support online software upgrading by net

Interface

Transducer socket

1. ECG
2. SPO2
3. NIBP
4. TEMP 1
5. TEMP 2 / Mainstream EtCO2
6. Sidestream EtCO2

veterinary monitor,pet monitor,patient monitoring systems,ecg monitor,vet monitor

Model F4 Patient Monitor
Dimension 175mm*210mm*80mm
Weight: 1.35kg(excluding accessories)
Power Supply -Adapter:  Output 13-20V DC, 5A
-Voltage: AC100~240V, 50/60HZ
lithium battery 14.8V/2200mAh
Charge Cycle: ≥500 times
Working time: 5.5 hours
Standard Config. 8 inch LED, 3/5 Lead ECG, NIBP, SpO2, Pulse Rate, Temperature, Respiration
Optional Config. EtCO2 (Mainstream/Sidestream/Microstream)
